Leak Detection in Cornwall, NY — Find It Before You Open a Wall
A water bill that jumped 30% with no change in usage. A ceiling stain that keeps reappearing after patches. A soft spot in the flooring with no visible source. These are signs of a hidden leak that's been running long enough to cause structural damage — and every day it runs is money lost and damage accumulating. Masters Plumbing Service uses acoustic ground microphones, thermal imaging cameras, and precision pressure testing in Cornwall, NY to locate leaks without speculative demolition.
4 Detection Capabilities We Bring to Every Leak Detection Call
No single detection method works for every leak scenario. Our technicians are trained on four distinct approaches and select the right tool — or combination of tools — based on the pipe type, building construction, and leak characteristics.
🎙️
Acoustic Ground Microphone
Acoustic detection is most effective on metal pipe (copper, cast iron) under slab or in concrete — materials that conduct sound efficiently. It works in quiet environments and requires shutting off the house briefly to establish a clean acoustic baseline.
🌡️
Infrared Thermal Camera
Thermal imaging is particularly effective inside insulated wall cavities and for finding the extent of moisture spread beyond the immediate leak point. It tells us not just where the pipe is failing but how far the moisture has already traveled.
📉
Pressure Decay Testing
We isolate the supply system, pressurize it to operating pressure, and monitor pressure over a timed hold period. Any pressure drop confirms active water loss from the supply side. By isolating zones — hot side vs. cold side, section by section — we narrow down which branch of the supply system is leaking before the detection phase begins.
💨
Tracer Gas Detection
For leaks that don't produce sufficient acoustic signature — very slow leaks, polyethylene pipe, or leaks deep under concrete — we can introduce a nitrogen/hydrogen tracer gas mixture into the isolated pipe and use a calibrated gas detector at the surface to find where the gas escapes. The detection sensitivity can locate leaks that produce no discernible pressure drop during a standard timed test.
What We Locate
Every Leak Detection Scenario We Handle in Cornwall, NY
Our detection service covers the full property, not just the obvious locations.
Under Slab
Slab Leak Detection
Confirmed slab leak location is documented with a marked point on the floor and provided to you in the written detection report, with coordinates relative to fixed reference points for the repair crew.
In-Wall
In-Wall & Ceiling Leak Detection
Wall and ceiling leaks are often traced by following a visible stain to its apparent high point — but the visible damage can be several feet from the actual pipe failure due to how water travels down framing members. Thermal imaging reveals the wet zone accurately, and acoustic equipment confirms the pipe location within the wall cavity.
Water Main
Underground Supply Line Detection
Supply lines between the meter and the structure run underground and are vulnerable to corrosion, ground movement, and tree root damage. A main supply line leak shows as unusually high meter usage with all interior fixtures off, sometimes with wet ground or sinkholes along the line path. Acoustic detection locates the failure in the buried line precisely enough to minimize excavation footprint.
Pool & Irrigation
Pool Line & Irrigation Leak Detection
Irrigation system leaks in main supply lines and lateral runs are found by isolating zones with the irrigation controller and pressure-testing each zone individually. Zone by zone testing narrows the failure to the smallest possible section.
Commercial
Commercial Property Leak Detection
Commercial water loss from undetected leaks often shows up as elevated utility bills for months before physical evidence appears. We can assess a commercial building's plumbing system for suspected leaks at the property owner's or property manager's request.
Documentation
Leak Detection Report for Insurance
Insurance claims for water damage from hidden leaks typically require documentation that the leak was not visible or detectable without specialized equipment. Our detection report includes: pressure test results confirming active water loss, detection method used, thermal imagery or acoustic mapping showing leak location, and technician certification information.
Our Systematic Leak Detection Approach in Cornwall
Here's exactly how a Masters Plumbing Service leak detection call plays out.
1
Initial Water Loss Confirmation
We start at the meter. All fixtures off, we watch the meter for 10 minutes. Movement confirms active water loss from the supply side. We also check for any visible evidence — water stains, soft floors, moisture readings with a moisture meter at suspect wall surfaces.
2
Zone Isolation & Pressure Decay
We isolate the supply system into zones — hot side, cold side, and if possible, individual branches — and pressure-test each zone to determine which branch is losing water. This narrows the area of active search significantly before detection equipment is deployed.
3
Detection Equipment Deployment
We document findings with thermal images and note detection readings at multiple grid points to triangulate the strongest signal.
4
Written Report & Repair Options
You receive a written detection report including pressure test results, detection method summary, leak location (described relative to fixed reference points), and thermal imagery. If you want us to repair the leak, we quote the repair and execute immediately. If you have your own plumber, the report gives them everything they need.
Customer Reviews
Real Leak Detection Reviews from Cornwall
★★★★★
High-efficiency home with a leak that defied normal detection. Water loss was slow — about 1.5 gallons per hour. The tech used tracer gas after pressure testing confirmed the loss but acoustic detection couldn't localize it clearly. Gas detection found the escape at a micro-fitting under the slab in the utility corridor. Impressive work.
— C. Thornton, Cornwall
★★★★★
Ceiling stain in the living room kept coming back despite two drywall patches. Masters Plumbing Service ran the thermal camera and found the wet zone was traveling from a supply line joint 9 feet away and flowing down a horizontal framing member — explaining why the patch kept failing. They marked the actual pipe location, we opened 8 inches of wall there, and the repair held. No more stain.
— B. Osei, Cornwall, NY
★★★★★
Pool was losing 2 inches of water per day — more than evaporation could explain. Masters Plumbing Service pressure-tested the plumbing circuit, isolated the issue to the return line, and ran acoustic detection along the line path to find the failure at a union fitting under the decking. Repair required pulling one deck board instead of the exploratory digging another company had proposed. Excellent, focused work.
— T. Anand, Cornwall, NY
Common Questions
FAQ — What to Know Before Booking Detection
Secondary indicators: water stains appearing or recurring in the same area without an obvious source; mold or mildew smell in rooms without a plumbing fixture; soft or discolored flooring; consistent sound of running water in walls when all fixtures are off.
In most cases, yes — the detection phase is entirely non-invasive. We locate the leak using acoustic, thermal, and pressure methods without any demolition. The detection tells us exactly where to open, which means the access opening is minimal rather than speculative.
For leaks in plastic pipe, low-pressure situations, or high-noise environments, accuracy may be lower and tracer gas becomes the preferred supplemental method.
We can provide supplemental information to claims adjusters on request, including equipment calibration records and a technical description of the detection methodology used.
A standard residential leak detection — confirming water loss, isolating the failing zone, and deploying detection equipment to locate the failure — typically takes 1.5–2.5 hours. More complex scenarios (multi-zone commercial, large properties, very slow leaks requiring tracer gas) can run 3–4 hours.
The repair quote is given before any wall or floor is opened. You know the full cost of detection + repair before anything is cut.
Service Area
Leak Detection Available Across Cornwall, NY
Masters Plumbing Service provides professional Leak Detection for residential and commercial properties throughout Cornwall and the surrounding Cornwall, NY service area. Detection appointments available most weekdays and Saturdays.
Non-Invasive Leak Detection in Cornwall, NY — Book Your Appointment
Masters Plumbing Service's detection team finds hidden leaks in Cornwall homes and commercial properties using equipment that eliminates guesswork. The detection appointment pays for itself the moment it prevents one unnecessary wall opening.
